V62/03642-01XE

Enhanced Product Configurable Multiple-Function Gate

Manufacturer：

Luminary Micro/Texas Instruments

copy

Manufacturer NO：

V62/03642-01XE

copy

Product SN：

10483-V62/03642-01XE

copy

Package/Case：

SOT-SC70 (DCK)-6

copy

Manufacturer Lead Time：

copy

Datasheet:

V62/03642-01XE Datasheet PDF

copy

Detailed Descripition：

Over-voltage tolerant inputs, Partial power down (Ioff), Very high speed (tpd 5-10ns)

copy

Product Application Field：None

0 In Stock

Finding Goods Through Sales

Want the lower wholesale price? Please send RFQ, we will respond immediately

Customer Reference

Quantity

Product price

Qty

Unit Price

Ext Price

1000

$0.649

$649

For more V62/03642-01XE prices, contact customer service to get a discount!

Documents & Media

Datasheets PDF V62/03642-01XE Datasheet PDF

Product Description

This configurable multiple-function gate is designed for 1.65-V to 5.5-V V_CC operation.

The SN74LVC1G97 features configurable multiple functions. The output state is determined by eight patterns of 3-bit input. The user can choose the logic functions MUX, AND, OR, NAND, NOR, inverter, and noninverter. All inputs can be connected to V_CC or GND.

This device functions as an independent gate, but because of Schmitt action, it may have different input threshold levels for positive-going (V_T+) and negative-going (V_T) signals.

This device is fully specified for partial-power-down applications using I_off. The I_off circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.

Controlled Baseline
- One Assembly/Test Site, One Fabrication Site
Enhanced Diminishing Manufacturing Sources (DMS) Support
Enhanced Product-Change Notification
Qualification Pedigree
Supports 5-V V_CC Operation
Inputs Accept Voltages to 5.5 V
Max t_pd of 6.3 ns at 3.3 V
Low Power Consumption, 10-µA Max I_CC
±24-mA Output Drive at 3.3 V
I_off Supports Partial-Power-Down Mode Operation
Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II
ESD Protection Exceeds JESD 22
- 2000-V Human-Body Model (A114-A)
- 200-V Machine Model (A115-A)
- 1000-V Charged-Device Model (C101)
Choose From Nine Specific Logic Functions
