V62/07646-01XE

Enhanced Product Dual Differential Comparators

Manufacturer：

Luminary Micro/Texas Instruments

copy

Manufacturer NO：

V62/07646-01XE

copy

Product SN：

10474-V62/07646-01XE

copy

Package/Case：

SOIC (D)-8

copy

Manufacturer Lead Time：

copy

Datasheet:

V62/07646-01XE Datasheet PDF

copy

Detailed Descripition：

-

copy

Product Application Field：None

0 In Stock

Finding Goods Through Sales

Want the lower wholesale price? Please send RFQ, we will respond immediately

Customer Reference

Quantity

Product price

Qty

Unit Price

Ext Price

1000

$0.682

$682

For more V62/07646-01XE prices, contact customer service to get a discount!

Documents & Media

Datasheets PDF V62/07646-01XE Datasheet PDF

Product Description

This device consist of two independent voltage comparators that are designed to operate from a single power supply over a wide range of voltages. Operation from dual supplies also is possible as long as the difference between the two supplies is 2 V to 36 V, and V_CC is at least 1.5 V more positive than the input common-mode voltage. Current drain is independent of the supply voltage. The outputs can be connected to other open-collector outputs to achieve wired-AND relationships.

The LM293-EP is characterized for operation from -55°C to 125°C.

Controlled Baseline
- One Assembly
- Test Site
- One Fabrication Site
Extended Temperature Performance of -55°C to 125°C
Enhanced Diminishing Manufacturing Sources (DMS) Support
Enhanced Product Change Notification
Qualification Pedigree⁽¹⁾
Single Supply or Dual Supplies
Wide Range of Supply Voltage
- Max Rating . . . 2 V to 36 V
- Tested to 30 V
Low Supply-Current Drain Independent of Supply Voltage . . . 0.4 mA Typical Per Comparator
Low Input Bias Current . . . 25 nA Typical
Low Input Offset Voltage . . . 2 mV Typical
Common-Mode Input Voltage Range Includes Ground
Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage . . . ±36 V
Low Output Saturation Voltage
Output Compatible With TTL, MOS, and CMOS
